New design flat top panel printing pallet nine feet pallet for paper stacking

Introduction

1.Nestable pallets suitable for Packaging and Printing Services;

2.Packaging Auxiliary Materials;

3.Packaging Machine;

4.Paper Packaging;

5.Pharmaceutical Packaging;

6.Logistics Packaging Printing Materials.

Product Details

Product Tags

Product Features

(1) The surface of the pallet must be flat,no flash, no cracks and deformations that affect the usage, and no burrs on the edges.

(2) Integrated injection molding, single-sided flat design, four sides are convenient for manual extraction, and improve work efficiency;

(3) There is a slope design at the entrance of the bottom surface, which is convenient for entering the fork from all sides, and is suitable for various styles of forklifts;

(4) Using high-density polyethylene (HDPE) raw materials, the product is Hygienic and clean, non-absorbent, moisture-proof, mildew-proof, anti-corrosion and insect-resistant, and has no nails and no thorns. Chip removal, recyclable;

(5) It is not easy to collapse and deform, more firm, and has strong product stability, load-bearing, cold resistance and heat resistance;

(6) The cross section of the bearing surface of the product is a “T”-shaped rib structure, which increases the bearing capacity of the bearing surface. The “T”-shaped panel will not affect the packaging.
Extrusion marks are formed on the product, which is beneficial to protect the outer packaging of the product;

(7) The mesh-type tie bars on the bottom surface are increased, and the four-side tensile rib is increased, so that the impact resistance is not easy to be deformed, and the bearing capacity is stronger and more stable.

Product Parameters

There are a lot of size available for your choice.

Product size

1000mm×800mm×140mm

Loading capacity

Static load

2.0 tons

Dynamic load

1.0 tons

Product weight

 10kg±3%

The main raw material of the product adopts high-density polyethylene (HDPE)

Operating temperature

 -30℃~60℃

Panel Type

Flat

Bottom Type

Nine Feet

Surface

Flat face design

Bottom

Encrypted Stretch

Production process

injection molding
